| Place of Origin: | JiangSu,China |
|---|---|
| Brand Name: | Barway |
| Certification: | CE, FCC, CCC, CTA |
| Model Number: | SD55 |
| Minimum Order Quantity: | 1pcs |
| Price: | 289-310USD |
| Packaging Details: | neutral packing |
| Delivery Time: | 7-15days |
| Payment Terms: | Western Union, L/C, T/T |
| Supply Ability: | 1000box per week |
| Item: | PDA | Operation: | Android 8.1 |
|---|---|---|---|
| CPU: | Octa-Core 2.0GHz | Warranty: | 1 Year |
| Memory: | 2GB+16GB | Weight: | 240g |
| Size: | 150mm*72.5mm*15mm | Certification: | CE, FCC, CCC, CTA |
| Highlight: | 5.5 inch Handheld Data Collector,Logistics Handheld Data Collector,4G pda android barcode scanner |
||
Barway 4G Rugged Logistics PDA Scanner Android Handheld Data Collector SD55 For Warehouse
Feature
Specification
|
SD55LG Basic Parameters
|
|
|
OS
|
Android 8.1
|
|
CPU
|
Octa-Core 2.0GHz
|
|
RAM
|
4GB
|
|
ROM
|
64GB
|
|
Expansion
|
Micro SD (TF) card slot up to 128GB
|
|
Keypad
|
5 Side buttons: 2 volume buttons,2 function buttons(1 left and right),
1 power button
|
|
Audio
|
1609 Dual speakers,waterproof design,Dual silicon mic noise reduction
|
|
Notification
|
Sound/vibration/LED prompt
|
|
Dimentions
|
150mm*72.5mm*15mm
|
|
Weight( with battery)
|
240g
|
|
Camera
|
|
|
Camera
|
Rear camera 13MP AF(16MP AF option);Front Camera 5MP FF
|
|
Focus mode
|
Autofocus ; Front focus
|
|
Flash
|
Support single color LED flash
|
|
Display
|
|
|
Display
|
5.5 Inch Full Screen
|
|
Resolution
|
720*1440 18:9
|
|
Touch Panel
|
5-point capacitive touch screen
|
|
Power
|
|
|
Battery
|
Large-capacity unremovable Li-ion battery 4500mAh
|
|
Charging
|
PE fast charging, fully charged time< 4 hours
Wireless charging QI standard, 5w or 10w |
|
Interface
|
Support USB-TypeC, support fast charge, support OTG
|
|
Communication
|
|
|
GPS
|
BT4.0 BLE
|
|
WLAN
|
WiFi 802.11 a/b/g/n 2.4G 5G
|
|
WWAN
|
FDD-LTE B1/B3/B5/B7 or B1/B4/B8/B13
TDD-LTE B38/B39//B40/B41 TDSCDMA B34/B39 WCDMA B1/B2/B5/B8 GSM B2/B3/B5/B8 CDMA1x/CDMA2000 BC0 |
|
GPS
|
GPS,GLONASS,BeiDou,AGPS,option UBLOX8030
|
|
Performance
|
|
|
Operation Temperature
|
-20℃ ~60℃
|
|
Storage Temperature
|
-30℃ ~+80℃
|
|
Humidity
|
5%~95%(No condensation)
|
|
Sealing
|
IP65
|
|
Sealing
|
In the operating range, 6 sides can withstand the impact of 1.5 meters
drop to the concrete floor
|
|
Tumble Test
|
6 contact surfaces rolling for 1000 times/ 0.5M
|
|
ESD
|
±15kV Air Discharge, ±8kV Contact Discharge
|
|
Certificate
|
CCC,CTA,CE,FCC
|
|
Extensibility
|
|
|
NFC RFID Reader
|
NFC (PN548) Support NFC Reader/writer, ISO14443-A/B/F, ISO18092, FeliCa, ISO15693
|
|
Barcode Scanner
|
1D/2D: CM60 or Speedata SD5670
|
|
|
|
|
PSAM
|
Support
|
|
Sensor
|
Geomagnetism, acceleration, light perception distance,berometer(optional),
gyroscope (optional)
|
Product&Application
5-point capacitive touch screen.
5.5inch with clear vision.
720*1440 resolution.
IP65 Protection.
GPS:High precision by ceramic antenna and u-blox chip.
Front 1609 speaker;Dual mic,noise reduction;Suitable for all noisy environment.
13Million HD Camera.
