| Place of Origin: | Jiangsu, China |
|---|---|
| Brand Name: | Honeywell |
| Certification: | RoHS,ce,FCC |
| Price: | $184.00 - $370.00/pieces |
| Packaging Details: | standard packing box |
| Products Status: | Stock | Type: | Flatbed Scanner |
|---|---|---|---|
| Scan Element Type: | Laser | Colour Depth: | 32 Bit, 32 Bit |
| Interface Type: | Usb, COM, PS/2 | Max Paper Size: | A4 |
| Optical Resolution: | >=5mil, >=5mil | Scan Speed: | 100/sec |
| Warranty(Year): | 1-Year | After-sales Service: | Others, Onsite Training And Inspection, Call Center And On-line Technical Support, Call Center And On-line Technical Support |
| Color: | Black | Advantage: | Up To 1.8m |
| Interface: | Bt/USB | Scan Angle: | Rotation 360 |
| Scan Pattern: | Area Image (838 X 640 Pixel Array) | Field Of View: | Horizontal 45°, Vertical 34° |
| Dimension: | 104mm*71mm*160mm | ||
| Highlight: | Barway Honeywell Mobility Barcode Scanners,Barway Honeywell Scanning Barcode Scanners,Barway Honeywell Flatbed Scanner |
||
|
Input Voltage
|
4 VDC to 5.5 VDC
|
|
Operating Power
|
2.3 W (450mA @ 5 VDC)
|
|
Standby Power
|
0.45 W (90mA @ 5 VDC)
|
|
Host System Interfaces
|
USB, Keyboard Wedge, RS232, IBM 46xx (RS485)
|
|
Environmental Sealing
|
IP41
|
|
Light Levels
|
0 to 100,000 lux (9,290 foot-candles)
|
|
Scan Pattern
|
Area Image (838 x 640 pixel array)
|
|
Motion Tolerance
|
Up to 610 cm/s (240 in/s) for 13 mil UPC at optimal focus
|
|
Scan Angle
|
HD Focus: Horizontal 41.4°; Vertical: 32.2°
SR Focus: Horizontal: 42.4°; Vertical: 33° ER Focus: Horizontal: 31.6°; Vertical: 24.4° |
|
Symbol Contrast
|
20% minimum reflectance difference
|
|
Pitch, Skew
|
45°, 65°
|
|
Decode Capability
|
Reads standard 1D, stacked, 2D and postal symbologies; limited OCR font reading
|
|
Dimensions (LxWxH)
|
104 mm x 71 mm x 160 mm (4.1 x 2.8 x 6.3inch)
|
|
Weight
|
147 g (5.2 oz)
|
